Chapter 2

Paper type

Any supported photo or plain paper media

How to load

1.Raise the Out tray (4).

2.Load paper print-side down. Press the Main tray release (2) and pull out the tray if needed for easier access. Check that the stack of paper is no higher than the top of the paper-length guide (3).

3.Adjust the Main tray paper-width guide (1), as needed.

4.Lower the Out tray (4).

Tray to load

Main tray

1 Main tray paper-width guide

2 Main tray release

3 Paper-length guide

4 Out tray

Any supported	1.	Load paper print-side
photo or plain		down into the front feed
paper media—ideal		slot (1). If you are using
for envelopes		tabbed paper, insert the
		paper so the tab feeds in
		last.
	2.	Adjust the front feed slot
		paper-width guide (3), as
		needed.

Front feed slot

1 Front feed slot

2 Out tray

3 Front feed slot paper-width guide

Stiff media, such as	1.	Load paper print-side up
cardstock (Not		into the rear feed slot (1).
supported: photo	2.	Adjust the rear feed slot
board and banner		paper-width guide (2), as
printing)		needed.

Tips

●To avoid jams and paper skewing, load one sheet at a time straight into the slot

●Use only stiff stock media

●Do not use for photo board or banner printing

●Only use this slot when printing from a computer. Not for use when printing from the printer's control panel.

Rear feed slot

1 Rear feed slot

2 Rear feed slot paper-width guide

12 HP Photosmart 8700 series
