TROUBLESHOOTING (cont.)











PROBLEM



PROBABLE CAUSE



REMEDY

Inconsistent beverage level in

1.

Improper water pressure



Check operating water pressure to

server/dispenser









the brewer. It must be between 20











and 90 psi (138 and 620 kPa).



2.

Brew valve



Test the brew valve. Refer to test











outputs on page 48. Turn the valve











on for 30 seconds and collect the











water dispensed from the spray-











head. Repeat the test several times











to confirm a consistent volume of











dispensed water. If not consistent,











check the valve, tubing and spray-











head for lime buildup.



3.

Bypass valve



If bypass is being used on the in-











consistent brewing recipe, test the











bypass valve. Refer to test outputs











on page 48. Turn the valve on for











30 seconds and collect the water











collected from the funnel. Repeat











the test several times to confirm











a consistent volume of dispensed











water. If not consistent, check the











valve, tubing and fittings for lime











buildup.



4.

Lime buildup



Inspect for lime buildup that could











block the tank, tank fittings, tubing,











valves and sprayhead.



5.

Brew volume adjustment



Adjust the brew volume, calibrate











sprayhead and bypass as required











to achieve the desired volume for











each brew cycle.

Page 37

41581.2 091609



Page 37
