The Configuration Page includes the following information:

qHardware Configuration

This section displays the hardware configuration of the machine, including any options that have been installed.

wCommon Settings

This section displays the common printer settings of the machine, as determined by the Set- tings menu. (See "Settings Menu," on p. 3-3.)

ePaper Feed

This section displays the paper feed settings for the printer function of the machine, as deter- mined by the Paper Feed section of the Settings menu. (See "Paper Feed," on p. 3-4.)

rPrint Quality

This section displays the print quality settings for the printer function of the machine, as deter- mined by the Print Quality section of the Settings menu. (See "Print Quality," on p. 3-6.)

tLayout

This section displays the layout settings for the printer function of the machine, as determined by the Layout section of the Settings menu. (See "Layout," on p. 3-7.)

yPCL Settings

This section displays the PCL settings for the printer function of the machine, as determined by the PCL section of the Settings menu. (See "PCL," on p. 3-20.)

uPS Settings (Printer Kit-C1 Only)

This section displays the PS settings for the printer function of the machine, as determined by the PS section of the Settings menu. (See "PS," on p. 3-22.)

6

Appendix

Configuration Page Sample

6-55
