4.Select [Aperture] by pressing the + or - button. Press the set button.

-+

SET

5.Select an aperture setting by pressing the + or - button. Press the set button.

Full Open: Aperture set to maximum. The F-Stop value will vary with the zoom setting.

Wide Angle (28 mm): F2.0

Telephoto (70 mm): F2.4

F2.8 - F8.0: The larger the value, the smaller the aperture

F8.0+ND4: Although the aperture is set to the F8.0 stop, an ND filter is used to emulate the brightness of an F16 stop (the aperture value is not F16)

6.Press the menu button. It will close the record menu. Each time you press the menu button it will either display the prior menu or close it.

The LCD monitor will automatically turn on and display the specified aperture setting.

•You can also press the shutter button halfway to close the menu directly.

Shooting

57

Image 59

Canon Pro70 manual F2.8 F8.0 The larger the value, the smaller the aperture
