12 プロジェクタの接続

DVD プレーヤへの接続

M1 - HDTV ケーブルを使った DVD プレーヤへの接続

D-sub - YPbPr ケーブルを使った DVD プレーヤへの接続

メモ：D-sub ‐ YPbPr ケーブルはデルからは提供されていません。ケー

ブルについてはインストール専門業者にお問い合わせください。

1電源コード

2M1 ‐ HDTV ケーブル

1電源コード

2D-sub - YPbPr ケーブル
