Heat & Glo LifeStyle 6000CL-IPI-S E. Vent Diagrams, Top Vent - Horizontal Termination, One Elbow

E. Vent Diagrams

Top Vent - Horizontal Termination

Note: The 6000/8000 series fireplaces can adapt to SLP series						WARNING
vent pipe, if desired.					Fire Risk.	Explosion Risk.
When venting off the top of the unit, use a DVP-2SL			adapter and a
minimum 48 inch vertical section of SLP series vent pipe.					Do NOT pack insulation or other combustibles
A DVP-SLP24 adapter may also be used with a 24 inch vertical					between ceiling firestops.
section of SLP series vent pipe.					• ALWAYS maintain specified clearances around
After the 48 inch vertical section, the venting table rules must be					venting and firestop systems.
					• Install wall shield and ceiling firestops as speci-
followed. The first 48 inch vertical section is NOT counted as part
of the vertical components in the table. It is still counted as part of					fied.
the overall maximum run. All venting table rules for the vent run					Failure to keep insulation or other material away
must still be followed.					from vent pipe may cause fire.
Example: DVP pipe 3 ft. min. vertical = 11 ft. max. horizontal						WARNING
SLP pipe 7 ft. min. vertical = 11 ft. max. horizontal
					Fire Risk.
					• When using DVP-HRC-SS and DVP-HRC-ZC-
					SS termination caps on top vented fireplaces, a
					6 inch minimum vertical vent section is required
Top Vent - Horizontal Termination					before installing first elbow.
One Elbow	6000CL-IPI				8000CL-IPI
V1 Minimum		H1 Maximum		V1 Minimum		H1 Maximum
Elbow only		2 ft	610 mm	Elbow only		2 ft.	610 mm
6 in.	152 mm	6 ft.	1.8 m	6 in.	152 mm	2 ft.	610 mm
1 ft.	305 mm	11 ft.	3.3 m	1 ft.	305 mm	5 ft.	1.5 m
1-1/2 ft.	457 mm	18 ft.	5.5 m	1-1/2 ft.	457 mm	10 ft.	3.0 m
2 ft.	1.2 m	25 ft.	7.6 m	2 ft.	610 mm	18 ft.	5.5 m
V1	+ H1 = 40 ft. (12.2 m) Maximum			2-1/2 ft.	762 mm	22 ft	6.7 m
	H1 = 25 ft. (7.6 m) Maximum			V1	+ H1 = 40 ft. (12.2 m) Maximum
					H1 = 22 ft. (6.7 m) Maximum

Note: For corner installations: A 6 inch (152

mm)section of straight pipe may need to be attached to the appliance before a 90º elbow, to allow the vent pipe to clear the top standoffs.

H1

V1

Figure 7.3

26

Heat & Glo • 6000CL-IPI-S, 6000CL-IPI-T, 8000CL-IPI-S 8000CL-IPI-T • 2165-900 Rev. S • 9/12
