F. Refractory Installation

CAUTION! Risk of Cuts, Abrasions or Flying Debris.

Wear protective gloves and safety glasses during instal- lation.

CAUTION! Refractory is fragile. Handle with care

Step 1. Back Refractory Panel Installation

The back refractory panel has a rectangular notch on the bottom side.

1.Hold the back refractory panel with the notch on the bottom facing down.

2.Place the back refractory panel against the back of the firebox. Ensure back refractory panel makes full contact with the back wall of the firebox. See Figures 1 and 2.

BACK WALL OFFIREBOX

EXPANSION BAR

8000 MODELS ONLY

DO NOT REMOVE

Figure 1

REFRACTORY

NOTCH

FOOT



LOWER



FIREBOX LIP



Figure 3

4.Slide the right refractory panel completely into the fire- box until it securely rests against back refractory panel. Make sure that right refractory panel makes full contact with the right sidewall of the firebox. See Figure 4.

Figure 2

Step 2. Right Refractory Panel Installation

The right refractory panel has a rectangular notch on the bottom side.

3.Place the right refractory panel against the right side- wall of the firebox. Rest the rectangular notch located on the bottom of the right refractory panel over the lower firebox lip. Let refractory foot rest on firebox af- ter panel’s notch has been mated with firebox lip. See Figure 3.

Figure 4

5.Verify that right refractory panel is slid all the way back by looking to see that it’s flush with the firebox lip.



REFRACTORY



PANEL MUST

NO GAPS

BE FLUSH WITH

LOWER FIREBOX





LIP

Figure 5

Heat & Glo • 6000CL-IPI-S, 6000CL-IPI-T, 8000CL-IPI-S 8000CL-IPI-T2165-900 Rev. S • 9/12

59
