Removal and Replacement Procedures

5.21 LED Board

LED Board Spare Part Number Information

For use on HP Pavilion dv1000 models

367797-001





For use on HP Compaq nx4800 and Compaq Presario V2000

367798-001

models







1. Prepare the computer for disassembly (Section 5.3) and remove the following components:

Hard drive (Section 5.4)

Optical drive (Section 5.8)

Switch cover (Section 5.9)

Keyboard (Section 5.10)

Display assembly (Section 5.11)

Base enclosoure (Section 5.12)

USB/S-Video controller board (Section 5.13)

Speaker assembly (Section 5.14)

System board (Section 5.20)

2.Turn the computer upside down with the front panel toward you.

5–62

Maintenance and Service Guide

Page 173
