Illustrated Parts Catalog
Table 3-5
Spare Parts: Sequential Part Number Listing (Continued)
Spare Part
Number Description
367784-001 Display assembly, 14.0-inch, WXGA for use on Compaq Presario V2000 models
367786-001 Hard drive, 60-GB, 4200-rpm (includes frame and connector)
367787-001 Hard drive, 40-GB, 4200-rpm (includes frame and connector)
367788-001 Hard drive, 80-GB, 4200-rpm (includes frame and connector)
367789-001 8X DVD-ROM Drive for use on HP Pavilion dv1000 models
367790-001 24X DVD/CD-RW Combo Drive for use on HP Pavilion dv1000 models
367793-001 Speaker assembly for use on HP Pavilion dv1000 models
367794-001 USB/S-Video controller board for use on HP Pavilion dv1000 models and HP Compaq nx4800 and
Compaq Presario V2000 models with a 1394 port, S-Video-out jack, expansion port, and digital memory card reader
367795-001 Fan (includes thermal pad)
367796-001 Heat sink (includes thermal pad)
367797-001 LED board for use on HP Pavilion dv1000 models (includes cable)
367798-001 LED board for use on HP Compaq nx4800 and Compaq Presario V2000 models (includes cable)
367799-001 System board for use on HP Pavilion dv1000 models with Intel Pentium M processors
367800-001 System board for use on HP Pavilion dv1000 models with Intel Celeron M processors
371693-001 Wired headset with volume control
Maintenance and Service Guide | 3–31 |
