Removal and Replacement Procedures

5.16 Menu Control Button Board

✎This section applies only to HP Pavilion dv1000 models.

Menu Control Button Board

Spare Part Number Information

Menu control button board (includes bracket and cable)

373535-001





1.Prepare the computer for disassembly (Section 5.3) and remove the following components:

❏Hard drive (Section 5.4)

❏Optical drive (Section 5.8)

❏Switch cover (Section 5.9)

❏Keyboard (Section 5.10)

❏Display assembly (Section 5.11)

❏Base enclosure (Section 5.12)

2.Position the top cover with the front panel toward you.
