<P=002>

Press 1 (MULTI COPY) if you do not

want the copies sorted. Press 2 (SORT

COPY) if you want the copies sorted.

Example of three

copies each of three

originals

MULTI SORT

ABC

ABCCCC

BBB

AAA

Originals

Sorted

(SORT COPY)

Not sorted

(MULTI COPY)

The display will show: ENTER # (01-99)

If you are making one copy per

original, press the START/MEMORY

key. If you are making multiple copies

per original, enter the number of c opies

per original (if the number is less than

10, enter a "0" before the number).

The display will show: COPY RATIO

Example: Nine

copies per original

Set the amount of reduction or

enlargement by entering a number

from 1 to 5 as shown below (or press

the START/MEMORY key to

automatically select 100%). Copying

will begin.

1: AUTO (automatic size adjustment to

match the size of the printin g paper)

2: 50%

3: 100% (no reduction or enlargement)

4: 125%

5: 135%

Example: 50%

4. Making

Copies

Making Copies
