Page 17

Starting and Stopping the Computer

Starting and Stopping the Computer

There are a number of ways to start and stop the computer.

Starting the Computer

You always start the computer using the power button .

A computer starts up with an operating system (OS) existing on the storage device such as the hard disk; or from a floppy disk or CD if you have the docking station installed. The computer will automatically load the OS after you turn it on. This process is called booting.

NOTE: An operating system is the platform for all your software application programs to run on. The most widely used operating system today is Microsoft Windows.

Stopping the Computer

When you finish a working session, you can stop the computer by turning off the power or leaving the computer in Standby or Suspend mode:

To stop in	Do this…		To start up or
this mode…			resume again

Off	Follow the shutdown procedure of your		Press the power
	operating system. This can prevent loss of		button		.
	operating system. This can prevent loss of		button		.
	unsaved data or damage to your software
	programs.

If the system is locked up because of hardware or software problems, press the

power button to turn off the computer.

Standby	Depending on your settings in Windows,			Press any key.
	you can put the computer in Standby
	mode by pressing the power button
	mode by pressing the power button

Suspend	Depending on your settings in Windows,			Press the power
	you can put the computer in Suspend

				button .
	mode by pressing the power button			button .
	mode by pressing the power button

2-2	Operating Your Tablet PC
