Genie 114002 Battery Charging Instructions, Battery and Charger Instructions Observe and Obey

Page 23

Third Edition • First Printing

Operator’s Manual









Battery Charging Instructions

Battery and Charger

Instructions

Observe and Obey:

Do not use an external charger or booster battery.

Charge the battery in a well-ventilated area.

Use proper AC input voltage for charging as indicated on the charger.

Use only Genie authorized battery and charger.

To Charge Battery

1Open the battery pack lid to access the battery.

2Remove the battery vent caps and check the battery acid level. If necessary, add only enough distilled water to cover the plates. Do not overfill prior to the charge cycle.

3Replace the battery vent caps.

4Be sure that the DC output cord is properly connected to the battery.

Black to negative, red to positive.

5Connect the battery charger to a grounded AC circuit.

6The charger will turn off automatically when the battery is fully charged.

7Check the battery acid level when the charge cycle is complete. Replenish with distilled water to the bottom of the fill tube. Do not overfill.

Dry Battery Filling and

Charging Instructions

1Remove the battery vent caps and permanently remove the plastic seal from the battery vent openings.

2Fill each cell with battery acid (electrolyte) until the level is sufficient to cover the plates.

Do not fill to maximum level until the battery charge cycle is complete. Overfilling can cause the battery acid to overflow during charging. Neutralize battery acid spills with baking soda and water.

3Install the battery vent caps.

4Charge the battery.

5Check the battery acid level when the charging cycle is complete. Replenish with distilled water to the bottom of the fill tube. Do not overfill.

Part No. 114002

Genie AWP Super Series

21
