NETGEAR ProSafe 802.11g Wireless Access Point WG302v2 Reference Manual

By default all traffic on the WG302v2 uses VLAN 1, which is the default untagged VLAN. Therefore, all traffic is untagged until you change the untagged traffic VLAN ID or the VLAN ID for a specific Security Profile. Check the Untagged VLAN check box to transmit all frames on the specified VLAN as untagged. If you clear the box, all traffic is tagged with a VLAN ID.

Time Zone. Select the Time Zone to match your location. If your location uses daylight saving, check the box Adjust for Daylight Saving Time.

The Current Time, as used on the wireless access point, is displayed.

Note: You must have an Internet connection to get the current time.

NTP Server. Click Enable to use a network time protocol (NTP) server to synchronize the clock in your access point, or click Disable if you do not want to use an NTP server.

Use Custom NTP Server. If you do not want to use the default NETGEAR NTP server, click this box and enter the hostname or IP address of the NTP server to use.

Wireless Settings

To configure the wireless settings, connect to the WG302v2 and click Wireless Settings in the Setup section of the WG302v2 main menu.

The Wireless Settings menu appears, as shown in Figure 2-6.

Figure 2-6

2-10

Basic Installation and Configuration

v1.0, May 2006
