20CHAPTER 2: INSTALLING THE ETHERNET ADAPTER

Attaching An

The Ethernet Adapter has two internal diversity dual-band antennas.

External Antenna

If you want to increase the range of the Ethernet Adapter, an external





antenna can be attached to the external antenna connector on the



Ethernet Adapter.



The Enterasys Networks-approved external antenna for this Ethernet



Adapter is the Enterasys Networks 2.4/5 GHz Omnidirectional Workgroup



Ethernet Adapter Antenna. For more information, go to



http://www.enterasys.com/products/wireless





Determining if you

If your network has a DHCP server and no special security requirements,

Need to Configure

you can most likely use the Ethernet Adapter just as it is shipped from the

the Ethernet

factory.

Adapter

It takes approximately one to two minutes for the Ethernet Adapter to





determine if there is a DHCP server on the network.



View the Ethernet Adapter’s default settings on page 22 to determine



whether or not you need to configure the Ethernet Adapter for your



network. If the factory defaults meet your requirements, you can connect



the Ethernet Adapter as described in “Connecting the Ethernet Adapter”



on page 15.



If your network does not have a DHCP server or is more complex, you



may have to configure the Ethernet Adapter and organize devices so that



you can manage the wireless LAN easily and keep it secure. You can use



the Enterasys Networks Wireless Infrastructure Device Manager (Widman)



included on the Enterasys Networks Installation CD.



For non-U.S. versions of the Ethernet Adapter, you need to set the Country



mode. This is done when you first open the Ethernet Adapter’s Configuration



Management System. See “Using the Configuration Management System” on



page 29 for instructions.



Networks with a DHCP Server



If your network has a DHCP server, an IP address is automatically assigned



to the Ethernet Adapter. It takes approximately one to two minutes for the



Ethernet Adapter to determine if there is a DHCP server on the network.



Use the Enterasys Networks Wireless Infrastructure Device Manager
