Panasonic KX-FC175AL TEL mode Answering all calls manually, Activating TEL mode, Handset

Page 48

Receiving Faxes

TEL mode!

(answering all calls manually)

Activating TEL mode

If the arrow (▼) is shown on the right of the display, turn it off by pressing PQ.

Display:	TEL MODE
Display:

ON

Receiving a fax using the base unit

1	When the unit rings, press
	NOor lift the handset and
2	press ‘to answer the call.
	When:
	— document reception is required,
	— a fax calling tone (slow beep) is heard, or
	— no sound is heard,
	press j.

	Display:		CONNECTING

AUTO ANSWER STOP DIGITAL SP-PHONE FAX/START

● The unit will start fax reception.		TALK
Receiving a fax using the		TALK
Receiving a fax using the		FAX RECEIVE
handset
1 When the handset rings, press ‘.	Note:
When:		If you do not answer the call within 10 rings,
2 — document reception is required,	●
		the unit will temporarily activate the
		answering device. The greeting message will
— a fax calling tone (slow beep) is heard, or		answering device. The greeting message will
— a fax calling tone (slow beep) is heard, or		then be played and the other party can then
— no sound is heard,		then be played and the other party can then
— no sound is heard,		send a fax.
press ˆuntil a single beep		send a fax.
press ˆuntil a single beep	● Up to 30 sheets of printed paper can be held.
is heard.		Remove the printed paper before it exceeds
● The unit will start fax reception.		30 sheets.
To stop receiving	Fax reception in memory

Press {.

Friendly reception feature

When you answer a call and hear a fax calling tone (slow beep), the unit will automatically start fax reception.

●If this feature is not required, set feature #46 to off (p. 75).

When a printing problem is detected, the unit will temporarily store the received document into memory.

While the document is in memory:

—the display will show an error message and the following alternately,

Display:	FAX IN MEMORY

—slow beeps will sound if feature #44 is set to on (p. 74).

●Follow the instructions on pages 79 and 80 to solve the problem.

●For memory capacity, see page 91.

48
