Panasonic KX-FP151E Pager call, Menu SET REDIAL/PAUSE, When your pager receives a pager call

Page 47
NO.=
4
5 Enter your pager number.
● You can enter a total of 46 digits and/or pauses.
Example:
1 202 555 1234PP12345678PP5555#
● If this feature is not required, select “OFF”.
Press w.

KX-FP151/155(E)(040-047) 01.12.19 10:10 AM Page 45

Receiving Faxes

Pager call!

This feature allows your unit to call your pager when your unit receives the following:

—For KX-FP151: a fax document.

—For KX-FP155: a fax document or an incoming voice message.

1

2

3

Press p.







Display:

SYSTEM

SET UP

PRESS NAVI.[I H]











Press #, then 70.











KX-FP151:

FAX

PAGER CALL

=OFF



[±]













KX-FP155:

PAGER

CALL

=OFF



[±]









Press +or -to select “ON”.







KX-FP151:

FAX

PAGER CALL

=ON



[±]



















KX-FP155:

PAGER

CALL

=ON



[±]





















MENU SET REDIAL/PAUSE

(pauses) MONITOR (KX-FP151)

DIGITAL SP-PHONE (KX-FP155)

















































Your pager Pauses











number





















Your pager access

















code, if required.







































Message you want













displayed on your pager.

6 Press w.

●The unit will dial the stored number.

PAGER TEST

7 Check that your pager received the pager test call.

8 Press q(KX-FP151)/ NO(KX-FP155).

When your pager receives a pager call

Your pager will display the message you entered in step

5. (For example: 5555)

45
