JVC HR-J765EK Selecting Sound You Want, Receiving Nicam Stereo And Bilingual Programmes

Page 20

20ADVANCEDOPERATIONS(cont.)

Selecting The

Sound You

Want

AUDIO

1 2 3

2

4 5 6

7 8 9

0

4

1

?

3

Receiving NICAM Stereo And Bilingual Programmes

Your recorder is equipped with a Digital stereo sound decoder (NICAM), making reception of stereo and bilingual broadcasts possible.

When the recorder is tuned to a different station, the type of broadcast being received will be displayed on the TV screen for a few seconds.

Type of Broadcast

On-screen Display

Being Received







Regular Monaural

(none)

NICAM Stereo

ST NICAM

NICAM Bilingual

BIL NICAM

NICAM Monaural

NICAM

●To listen to a stereo programme, press AUDIO until

"HI FI L R" appears on the screen.

●To listen to a bilingual programme, press AUDIO until "HI FI L " or "HI FI R" appears on the screen (as required).

●To listen to the Standard (regular monaural) audio while receiving a NICAM broadcast, press AUDIO until "NORM" appears on the screen.

NOTES:

●The NICAM audio programme will be recorded on the Hi-Fi audio track, and the Standard audio programme on the normal audio track.

●If the quality of stereo sound being received is poor, the broadcast will be received in monaural with better quality.

●Before playing back a programme recorded in stereo, or a bilingual programme, refer to "Soundtrack Selection" (See below).

●"O.S.D." must be set to "ON" or the on-screen displays will not appear (☞ pg. 26).

Soundtrack Selection

Your video recorder is capable of recording three soundtracks (HI-FI L, HI-FI R and NORM) and will play back the one you select.

During Playback

Pressing AUDIO on the remote control changes the soundtrack being played back as follows:

TRACK

USE











On-Screen Display

















HI FI

For Hi-Fi stereo tapes

L







R





















L

HI FI

For main audio of Bilingual tapes



























HI FI

For sub audio of Bilingual tapes









R











NORM

For audio-dubbed tapes









HI FI

For audio-dubbed tapes

NORM



NOTES:

●"HIFI L R" should normally be selected. In this mode, Hi-Fi stereo tapes are played back in stereo, and the normal audio track is played back automatically for tapes with only normal audio.

●For instructions on recording NICAM stereo and bilingual programmes (See above).

●Bilingual programmes are not currently broadcast in the U.K.

●"O.S.D." must be set to "ON" or the on-screen displays will not appear (☞ pg. 26).
