Divar Installation Manual Menu system

EN 5-12

The entire history list is erased if you select the Clear History item.

Date/time changes of stored video are always logged and cannot be disabled or cleared.

>>LOCAL PASSWORDS

Set or change the password that allows access to playback functions.

Set or change the password that allows access to the configuration functions.

Use the camera keys (1 to 9) on the front of the unit to enter a four-digit password in the dialog box that appears.

Enter the same password again to have it verified.

Press F2 to remove password protection.

>>CONNECTIVITY

The Connectivity menu gives access to settings that control the behavior of the unit with respect to all external devices or a network. It also gives access to settings for connecting multiple units to each other and for connecting computers via the communications port.

>>>Keyboard access restrictions

Four external keyboards can be connected to the unit.

Allow these keyboards to control monitor A only, monitor B only, both or neither.

>>>Network setup

Set DHCP to Yes to have IP address, subnet mask and default gateway assigned automatically by the network server. The actual values are displayed.

Enter a Divar name to be used in the network.

Fill in the IP, subnet mask and default gateway addresses when DHCP is set to No. If required, change the default http port (80) to a new value. The MAC address is read only.

If Discovery is set to Enabled, the Control Center can carry out automatic discovery and read the IP address of the unit.

Restrict the network bandwidth by entering an Mbps between 0 and 100 for the bandwidth limit.

>>>Network access

Access to the unit via the network can be set for up to six different users.

Restrict access to the unit by listing an IP address range. The range you use will normally depend on your network setup.

Select a user number to set up the configuration for that remote user. The administrator is user 1 and is identified as

ADMINISTRATOR.

IP Range

Eight IP ranges can be entered to allow access.

Enter the same begin and end address to specify a single IP address. Enter different begin and end addresses to specify an IP address range.

Use the up/down arrow keys to move to an IP entry. Press the select key to edit the entries. Press F1 to set the default values (000.000.000.000 to 255.255.255.255).

List of Users

Enter a name, up to 16-characters long, for each user. Enter a password up to 12-digits long.

Set User Rights to Live to restrict viewing rights to live video only.

Select the cameras in the Camera Lock Out submenu that are not accessible for the user.

Set the camera sequence list and dwell time (from 3 to 59 seconds) for the remote viewer. All connected cameras are listed by default.

Set Camera Control to allow control of controllable cameras remotely.

>>>Expand system

When you have multiple units linked, give each unit a unique identification number (from 1 to 30).

Enter a first camera number (from 1 to 999) to offset the camera numbers for the different Divars.

Only default camera identification numbers (Camera 1, Camera 2, etc.) are offset.
