Canon S5 IS 2, 3, 4

Advanced Shooting Functions

Moving the AF Frame

When the shooting mode is , , or , the AF frame can

be moved manually to th e desired area (Activ e Frame Control).

1 (Rec.) Menu [FlexiZone] [On]*/[Off].

See Menus and Settings (p. 27).

*Default setting.

2Press the button.

zThe AF frame appears in green.

3When moving the AF frame to

the face of the subject, press

the MENU button.

4Move the AF frame to the position you wish

to set using the S, T, W or X button, then

press the button.

zThe AF frame will move back to its original position (center),

if you hold down the button.

zWhen the Spot AE Point is selected a s the metering mode,

you can use the selected Spot AE Point as the AF frame

(p.78).

zSelection cannot be made while in the manual focus mode

(p.75).

zThe position of the AF frame returns to the center once the

power is turned off or the lens is retracted in playback mode

(Basic Guide p. 7).
