Removal and Replacement Procedures
5.19 Disk Cell RTC Battery
Disk Cell RTC Battery
Spare Part Number Information
Disk cell RTC battery | |
|
|
1.Prepare the computer for disassembly (Section 5.3) and remove the following components:
a.Hinge covers (Section 5.5)
b.Keyboard (Section 5.6)
c.Display (Section 5.7)
d.EMI shield (Section 5.8)
e.Top cover (Section 5.9)
f.Infrared board (Section 5.15)
g.System board (Section 5.16)
2.Turn the system board bottom side up with the rear panel facing you.
