Compaq N150 Maintenance and Service Guide 615

Specifications

Maintenance and Service Guide 6–15

I/O Address(hex) System Function (shipping configuration)

2F0 - 2F7 unused

2F8- 2FF Infraredport

300 - 31F unused

320 - 36F unused

370 - 377 Secondary diskette drive controller

378 - 37F Parallel port (LPT1/default)

380 - 387 unused

388 - 38B FMsynthesizer - OPL3

38C - 3AF unused

3B0 - 3BB VGA

3BC - 3BF Reserved (parallelpor t/no EPP support)

3C0 - 3DF VGA

3E0 -3E1 PC Card controller in CPU

3E2- 3E3 unused

3E8 - 3EF Internal modem

3F0 - 3F7 “A” diskettecontroller

3F8 - 3FF Serialpor t (COM1/default)

CF8 - CFB PCIconfiguration index register (PCIDIVO-1)

CFC - CFF PCIconfiguration data register (PCIDIVO-1)

Table 6 -11

System I/O Addresses

(Continued)
