Compaq N150 5.18 Mini PCI Board

Removaland Replacement Procedures

Maintenance and Service Guide 5–35

5.18 Mini PCI Board

1. Prepare the computer for disassembly (Section 5.3) and

removethe following components:

a. Hinge covers (Section 5.5)

b. Keyboard(Section 5.6)

c. Display (Section 5.7)

d. EMI shield (Section 5.8)

e. Topc over(Section 5.9)

f. Infrared board (Section 5.15)

g. System board (Section 5.16)

2. Turnthe system board bottom side up with the rear panel

facing you.

Mini PCI Board

Spare Part Number Information

Mini PCI boards

TypeIII mini PCI combination 56 Kbps modem/NIC board

TypeIII mini PCI 56 Kbps modem board

233558-001

233557-001
