6
Specifications
This chapter provides physical and performance specifications.
Table
Computer
Dimensions |
|
|
Height | 12.2 in | 309 mm |
Depth | 1.3 in | 34 mm |
Width | 9.8 in | 248 mm |
|
|
|
Weight (with | 5.9 lb | 2.7 kg |
TFT display and Li ion |
|
|
battery) |
|
|
|
| |
Standalone (Battery) Power Requirements |
| |
Nominal operating | 14.8 VDC |
|
voltage (Li ion) |
|
|
Nominal operating | 11.1 VDC |
|
voltage |
|
|
Li ion) |
|
|
|
| |
AC Adapter Power Requirements |
| |
Operating voltage | 100 to 240 VAC RMS nominal | |
Operating current | 1.3 A RMS |
|
Operating frequency | 50 to 60 Hz AC nominal |
|
range |
|
|
Maximum transient | 4/50 kV |
|
|
|
|
Temperature |
|
|
Operating | 50° to 95°F | 10° to 35°C |
Nonoperating | ||
|
|
|
Maintenance and Service Guide |
