Specifications

Optical mechanism system

• Projection method

3D-ILA device, 1 lens, 3 primary color optical shutter method

D-ILA device

1.3" measured diagonally (2 048 pixels ×1 536 pixels) × 3 (Total number of pixels : 9 437 184)

• Projecting lens

GL-MQ1010G

1:1 fixed focus lens

(separately available)

GL-MQ1015SG

1.5:1 fixed focus lens



GL-MQ1020ZG

2.1:1 to 4.9:1 zoom lens



GL-MQ1023SZG

3:1 to 7:1 zoom lens

• Screen size

60" to 300" [recommended] to 867" [maximum] measured diagonally (*with aspect ratio : 4 : 3)

Light-source lamp

2.0 kW xenon lamp



Electrical system

• Resolution

2 048 dots × 1 536 dots (QXGA full resolution, during RGB input)

• Scanning frequency

Horizontal frequency : 31.5 kHz to 135 kHz



Vertical frequency : 48 Hz to 120 Hz



(When HD signal is input, 24 Hz, 25 Hz, and 30 Hz are available.



For details, refer to page 44.)

Input / output

[RGB IN (RGB input)]



1-line, BNC × 5



Analog RGB signal





R

: 0.7V(p-p), 75Ω



B

: 0.7V(p-p), 75Ω



G

: 0.7V(p-p), 75Ω



G on sync

: 1V(p-p), 75Ω (negative sync)



Horizontal sync/composite sync signal (H/Cs)





H

: 1V(p-p) to 5V(p-p), high impedance (positive/negative polarity)



Cs

: 1V(p-p) to 5V(p-p), high impedance (positive/negative polarity)



Vertical sync signal (V)



V

: 1V(p-p) to 5V(p-p), high impedance (positive/negative polarity)



* Some connected devices may not correspond to composite sync (Cs) or G on sync signal.



Horizontal frequency





: 31.5 kHz to 135 kHz



Vertical frequency





: 48 kHz to 120 kHz



Dot clock

: 25 MHz to 280 MHz

[CONTROL]









RS-232C IN

: 1-line, D-sub 9-pin × 1



* RS-232C-interface specified control terminal for controlling this projector with a personal



computer.







RS-232C OUT

: 1-line, D-sub 9-pin × 1



* RS-232C-interface specified control terminal for controlling other projectors with a personal



computer connected to this projector.

• REMOTE

: 1-line, mini-jack × 1









(To be continued on the next page)

ENGLISH

59
