Orion 2xx manual 5.1.2Status Messages, Display Message, Action, Comment

5.1.2Status Messages

Display Message	Action	Comment
OK	None	Normal operating mode
Initial	None	Shown at power-up during
		self check
Default Cal	Factory set default calibration parameters	Consult Factory
	are in use, level reading may be inaccurate
Lo Temp	Present temperature in electronics	Transmitter may need to be moved
	compartment is below -40° C	to ensure temperature is within
		specification
Hi Temp	Present temperature in electronics	Transmitter may need to be moved
	compartment is above +80° C	to ensure temperature is within
		specification
Float 2	No level signal detected from float 2	Make sure 2 floats are being used,
Fail		are not damaged, and within
		measuring range
Float 1	No level signal detected from float 1	Make sure float is not damaged
Fail		and within measurement range
No Signal	No signal detected from any float	Make sure float is not damaged
		and within measurement range
Snsr Brd Fail	No signal from probe, bad board or	Check electrical connections
	connection problem	to probe
DfltParm	Internal non-volatile, parameters have	Consult Factory
	been defaulted

46-649 Jupiter Magnetostrictive Transmitter - FOUNDATION fieldbus™ 20
