Rear
NonPublish
1. NETWORK: Data input from a network.
2. EXT 2 (SCART): Analog audio and video
input from analog or digital devices such as
DVD players or game consoles.
3. SERV. U: For use by service personnel
only.
4. EXT 3 Component (Y Pb Pr) : Analog
audio and video input from analog or digital
devices such as DVD players or game
consoles.
5. : Stereo audio output to headphones or
earphones.
Bottom
NonPublish
1. EXT 1 (SCART): Analog audio and video
input from analog or digital devices such as
DVD players or game consoles.
2. DIGITAL AUDIO OUT: Digital audio
output to home theaters and other digital
audio systems.
3. HDMI: Digital audio and video input from
high-definition digital devices such as Blu-ray
players.
