Top Page > Fun Features with Connected Equipment > PC

Enjoy music, pictures and other content from your PC by connecting it with dedicated cables.

TV

Audio cable (not

supplied)

D-sub 15 cable (not supplied)

For some Apple Macintosh computers, it may be necessary to use an adapter (not supplied). If an adapter is used, connect the adapter to the computer before connecting the HD15-HD15 cable.

You can connect an HDMI-compatible PC with an HDMI cable.

PC Input Signal Reference Chart

VGA

-Horizontal (Pixel)/Vertical (Line): 640/480

-Horizontal frequency (kHz)/Vertical frequency (Hz): 31.5/60

-Standard: VGA

SVGA

-Horizontal (Pixel)/Vertical (Line): 800/600

-Horizontal frequency (kHz)/Vertical frequency (Hz): 37.9/60

-Standard: VESA Guidelines

XGA

-Horizontal (Pixel)/Vertical (Line): 1024/768

-Horizontal frequency (kHz)/Vertical frequency (Hz): 48.4/60

-Standard: VESA Guidelines

WXGA

-Horizontal (Pixel)/Vertical (Line): 1280/768, 1280/768, 1360/768

-Horizontal frequency (kHz)/Vertical frequency (Hz): 47.4/60, 47.8/60, 47.7/60
