Page 55

Setup Codes for TVs (DLP)

Hewlett Packard	11494
HP	11494
LG	11265
Magnavox	11525
Mitsubishi	11250
Optoma	10887
Panasonic	11291
RCA	11447
Samsung	10812, 11060, 11312
SVA	10872
Toshiba	11265, 11306
Vizio	11499
Setup Codes for TVs (LCD)
Accurian	11803
Action	10873
Akai	11675, 11676, 11935
AOC	11365
Apex Digital	10890, 11217
Astar	11531, 11548
Audiovox	10180, 10710, 10802,
	10846, 10875, 11284,
	11937, 11951, 11952
BenQ	11315

Byd:sign	11309, 11311

Cadia	11283

Citizen	11935

CyberHome	10794

Dell	11080, 11178, 11264

Emprex	11422, 11546

Envision	10813, 11365

FlexVision	10710

Funai	10171

Go Video	10886

Hannspree	11348, 11351

Hewlett Packard	11088, 11642

55

Image 55
