Chapter 4 Troubleshooting the System

Understanding Show Command Responses

Table 4-18 Show Interface Cable Upstream Command Field Descriptions









Field

Description











Cable

Indicates the location of the upstream interface























Upstream is

Indicates the administrative state of the upstream interface









up/...administratively down





























Received broadcasts

Number of broadcast packets received through this











upstream interface























multicasts

Number of multicast packets received through this











upstream interface























unicasts

Number of unicast packets received through this interface























discards

Number of packets discarded by this interface























errors

Sum of all errors that prevented upstream transmission of











packets through this interface























unknown protocol

Number of packets received that were generated using a











protocol unknown to the Cisco uBR7246























packets input

Number of packets received through this upstream











interface that were free from errors























corrected

Number of error packets received through this upstream











interface that were corrected























uncorrectable

Number of error packets received through this upstream











interface that could not be corrected























noise

Number of upstream packets corrupted by line noise























microreflections

Number of upstream packets corrupted by











microreflections























Guaranteed-rate service queue

Number of bandwidth requests queued up in the









depth

Guarantee-rate queue. This queue is only available to











modems that have a reserved minimum upstream rate in











their Class of Service























Best-effort service queue depth

Number of bandwidth requests queued up in the











Best-effort queue. This queue is available to all modems











that do not have any reserved rate on the upstream























Total Modems On This

Number of cable modems currently sharing this upstream









Upstream Channel

channel. This field also shows how many of these modems











are active























Current Total Bandwidth

Total amount of bandwidth reserved by all modems









Reserved

sharing this upstream channel that require bandwidth











reservation. The Class of Service for these modems











specifies some non-zero value for the guaranteed-upstream











rate. When one of these modems is admitted on the











upstream, this field value is incremented by this











guaranteed-upstream rate value



















Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide

























4-28







78-5897-01
