Panasonic KX-TG6700 Setting up the handset, Connecting the charger KX-TG6702 only

Page 12

Preparation

Setting up the handset

Connecting the charger (KX-TG6702 only)

LUse only the included Panasonic AC adaptor PQLV207.

(120 V AC, 60 Hz)

Bottom of	Hooks
the charger

Fasten the AC adaptor cord to prevent it from being disconnected.

Note:

LThe AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.)

LThe AC adaptor should be connected to a vertically oriented or floor-mounted AC outlet. Do not connect the AC adaptor to a ceiling-mounted AC outlet, as the weight of the adaptor may cause it to become disconnected.

Battery installation/replacement

1 Press the notch of the handset cover firmly, and slide it in the direction of the arrow.

LIf necessary, remove the old battery.

2 Insert the battery (A), and press it down until it snaps into position (B). Then close the handset cover (C, D).

B

C

A

D

Important:

LUse only the rechargeable Panasonic battery noted on page 5.

Attention:

A nickel metal hydride battery that is recyclable powers the product you have purchased.

12For assistance, please visit http://www.panasonic.com/phonehelp
