Panasonic KX-TG6700, KX-TG6702 operating instructions Controls, Base unit

Page 15

Preparation

Controls

Base unit

A B C DE F G H N ON

LINE1

LINE2



I

J

K L M

P

Q RS TU V

WXYZ

A {ERASE}

N Antenna



B {MEMO}

O Speaker



C Display

P Charge contacts



D {GREETING CHECK}

Q {*} (TONE)



E {GREETING REC} (Recording)

R {PAUSE} {REDIAL}

F {LINE SELECT}

S {FLASH} {CALL WAIT}

G {ANSWER ON}

T {MUTE}



H {MESSAGE}

U {SP-PHONE}(Speakerphone)

I {LINE1}

SP-PHONE indicator

LINE1 indicator

V MIC (Microphone)

J {LINE2}

W Navigator key ({^} {V} {<} {>})

LINE2 indicator

X {AUTO} {PROGRAM}

K {STOP}

Y {CONF} (Conference)

L IN USE indicator

Z {HOLD}



M{TRANSFER} {INTERCOM}

For assistance, please visit http://www.panasonic.com/phonehelp

15
