Setting up sources

This section describes how to use the Meridian Configuration program to configure the sources provided by the digital active loudspeaker.

To set up sources

●Click the Sources icon in the left-hand panel of the Meridian window.

The right-hand panel shows a list of the 12 sources that are available. For each source you can configure its audio, tone, and advanced settings.

To configure the source options

●Select the source in the list of sources.

The settings for the source are shown in a panel to the right:

Configuring the DSP33 loudspeakers using

To change the name used to identify the source when using RS232 control:

●Choose a name from the Name drop-down menu.

a computer

31
