Page 49

USER MANUAL

PROBLEMS AND REMEDIES

The following table shows the most common problems that may arise during the use of the machine, the possible causes and the suggested remedies to solve them.

WARNING!

When applying a recommended solution, always follow the instructions relating to it.

NOTE

Do not hesitate to contact Nilfisk-Advance if a problem cannot be solved by following the instructions provided.

PROBLEMS AND REMEDIES

PROBLEM

CAUSE

REMEDY

Heavy material not collected/traces of dirt

Excessive drive speed

Decrease drive speed

left behind during use





Light print

Adjust print











Worn out broom

Replace the brooms









Broom bristles bent or tangled with steel wire,

Remove any tangled material



ropes etc.









Excessive amount of dust left on the ground

Fan off

Switch on the fan

or coming out of skirts





Clogged filters

Clean filters









Material is thrown forward

Broken skirt gasket

Replace







Engine fails to start



See Troubleshooting in the engine Manual







Machine power is reduced

Insufficient pump oil feed

Check by-pass screw tightening





Check pump pressure (16 to 20 Bar)





Overhaul motor









Worn motors

Overhaul pump







The machine fails to run

Open by-pass

Check by-pass screw tightening









Faulty pedal control

Check pressure/replace pedal









No power to pump or motors

Overhaul motor





Overhaul pump







Machine fails to brake

No brake fluid

Top up fluid tank









Brake fluid pump failure

Overhaul pump









Air inside the system

Bleed system









Jaw cylinders failure

Replace cylinders









Worn or greasy brake lining

Replace brake lining







Hard power steering

Locked power steering

Replace power steering









Faulty priority valve

Overhaul/replace priority valve







Hopper fails to lift/lower

Locked distributor

Check distributor









Locked cylinder

Check cylinder







Waste loss from hopper

Broken hopper gasket

Replace gaskets







Filter shaker fails to operate

Broken push-button

Replace









Blown fuse

Replace









Excessive motor absorption causes:

Replace



– Worn carbon brushes



– Dirty or worn bearings

Replace



– Burnt armature or winding.

Replace







Blown filter shaker fuse

Excessive motor absorption

(see above)









Faulty fuse

Replace









Shorted cable

Check system







Noisy fan

Motor failure

Overhaul motor







Fan fails to operate

No voltage to motor

Check electrical system









Motor failure

Overhaul motor







Skirt fails to open

No pressure to cylinder

Check cylinder









Locked linkage

Check linkage







Skirt gasket lifted by broom

Skirt gasket too long

Shorten/replace







Poor suction

Motor failure

Overhaul motor









Clogged or broken closed pocket filter

Clean/replace filter







33014815(1)2005-07 A
