Dell Network Management Card (Optional)
The Dell Online Rack UPS has one available communication bay, which supports the optional Dell Network Management Card. See Figure 22 for the location of the communication bay.
It is not necessary to shut down the UPS before installing a communication card.
1Remove the slot cover secured by two screws. Retain the screws.
2Insert the communication card into the slot.
3Secure the card with both screws.
Figure 22. Dell Network Management Card
For details on disabling control commands from the Dell Network Management Card, see the Control Commands from Serial Port setting on page 42.
Refer to the Dell Network Management Card User's Guide for more information.
