162Camera Settings

5 Function

Formatting the SD Memory Card

Be sure to format new SD Memory Card with the camera before using the card.

Formatting will delete all the data on the SD Memory Card.

• Do not open the card cover while formatting SD Memory Card. The card may be damaged beyond use.

• Formatting will delete protected data. Be aware.

1 Select [Format] on the [HSet-up] menu (p.99).

2 Press the four-way controller (5) to display the Format screen.

Reference

3 Use the four-way controller (2) to select [Format].

Format

All data deleted

Format

Cancel

OK OK

4 Press the 4button.

Formatting starts. When formatting is completed, the camera is ready to take pictures.
