Playback
+
+
O
Y
A
L
P
|
|
|
| M |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| A |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| F |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| O |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Y |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| A |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| L |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| P |
|
|
|
|
|
|
|
|
|
|
|
Power switch |
|
|
|
|
|
| |||||||||
|
|
|
|
|
|
|
|
|
|
| VIDEO indicator | ||||
|
| STOP |
|
|
|
| R |
| RETAKEF |
| |||||
LIGHT | AUTO ON |
|
| / M |
|
|
|
|
|
|
|
|
| CHARGE DSC VIDEO REFRESH | EJECT |
|
|
|
| R |
|
|
| I P | E |
|
|
|
| T |
|
| OFF |
| E | R |
|
|
|
|
|
|
|
|
| ||
| T |
|
| E | / W |
|
| E |
| I F | E | C |
| ||
|
| N |
|
|
|
|
|
|
|
|
|
| |||
|
| U |
|
| F A | D |
|
| P . | A | D I | G |
|
|
|
|
| C O |
|
|
|
|
|
|
|
|
|
| |||
Playback buttons
Playback on a TV (or VCR) with Audio/Video Input Jacks
1.Turn on the TV and tune it to the video input channel or turn on VCR and place it in the “line” or “camera mode”. (If your VCR does not have a “line” or “camera mode”, consult the VCR owner’s manual.) Operate the TV as you normally do to see the signal coming from the VCR.
2.Set the Power switch to playback
mode. (The VIDEO indicator comes on.)
3.Press
/
.
•During playback, use the playback features (see page 46).
4.Press STOP when you are finished.
Notes:
•It is recommended to use the power supply instead of the battery pack for power to achieve uniform playback.
•Adjust the TV sound volume to its minimum level to avoid a sudden burst of sound when the camcorder is turned on.
•If you have a TV or speakers that are not specially shielded, do not place the speakers next to the TV as interference will occur in the camcorder playback picture.
•To view the picture and sound from the camcorder without recording, set the camcorder’s Power switch to A or M , then set your TV to the appropriate input mode.
Chapter 4 | 55 |
