Chapter 5 - Operating instructions
5.6.4Precision focus
☞Note
Set the Lens Interface to digital in the LENS menu before using precision focus.
The camera supports the precision focus feature which is offered by some advanced (digital) lenses. This system automatically focuses the image within a user defined focus frame on the screen. When precision focus is enabled on the lens, the focus frame is superimposed on the viewfinder image. The frame can be moved and resized by the controls on the lens or on the focus handle.
- |
| + |
| ++ |
| REC |
| MEDIA |
| BATT |
| ND/RE |
| FOC+ |
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
0
3.2
4.7
5.6
7.5
FL
AW1
AW2
!
auto focus frame
focus indicator
An indicator in the bottom left corner of the viewfinder screen shows the current focus information:
Indication | Focus information |
|
|
- - | focus is behind |
|
|
- | focus is behind |
|
|
0 | area is in focus |
|
|
+ | focus is in front |
|
|
+ + | focus is in front |
|
|
Refer to the documentation of the lens manufacturer for more information about the precision focus feature.
5.6.5 Lens indicators in the viewfinder
The ND/RE indicator in the viewfinder lights when a lens range extender is selected.
The Iris indicator in the viewfinder shows the value of the iris opening (when enabled in the VF menu).
The Zoom indicator in the viewfinder shows the degree to which the lens has been zoomed out or in ranging from 0 (wide angle) to 99 (tele). It shows 50 if the lens does not support this feature.
