Chapter 5 - Operating instructions
5.7.8 Reverse scan
When the camera is used in a mounted at a rotated angle use the reverse scan feature to digitally rotate the camera’s image to compensate. Go to the INSTALL\REVERSE SCAN menu to switch reverse scan on or off and to select the scan mode (horizontal, vertical or both rotations).
5.7.9 Black stretch
The black stretch function changes the level of detail in the shadow areas of the picture without effecting the rest of the picture. Set the Black stretch switch to the On position to switch on the black stretch function.
The Video menu allows you to adjust the black stretch parameters. Black stretch values above 50 produce more detail in the shadow areas, while values lower that 50 reduce the detail (this is often referred to as Black Press). The default value is 99.
When black stretch is switched on the
5.7.10 Auto skin detail
Use skin detail to change the detail level in a selected colour range. Decreasing the detail level of a persons skin colour softens only the skin tones. But not only skin colours can be selected, for example, decrease the detail level of a soccer field to accentuate the soccer players or increase the skin detail level to accentuate a rough surface.
Carry out the Auto skin detail procedure as follows:
1.In the VIDEO\SKIN\SKIn menu, select the memory position skin 1 or skin 2 (not 1+2).
2.Place the cursor in front of the VIDEO\SKIN\AUTO item.
3.Press the Select button. The following appears in the viewfinder.
-
+
++
REC
MEDIA
BATT |
| ND/RE |
| FOC+ |
3.2
ASKIN: window
4.7
5.6
7.5
FL
AW1
AW2
!
4.Point two small white boxes at the intended surface.
5.Press the Select button to start the measurement procedure (the iris is set to Auto). The process running message appears:
-
+
++
REC
MEDIA
BATT |
| ND/RE |
| FOC+ |
3.2
ASKIN: running
4.7
5.6
7.5
FL
AW1
AW2
!
