Specifications

System

Video recording system Two rotary heads, Helical scanning system

Audio recording system

Two rotary heads, PCM system

Video signal

NTSC color, EIA standards

Usable cassette

DVCAM logo printed cassette

Recording / Playback time (using PDV-184ME cassette)

184min.

Fastforward/rewind time

Approx. 7 min.

Image device

3CCD (Charge Coupled Device 1/3")

Viewfinder

Electronic viewfinder: Monochrome

Lens

10x (optical), 20x (digital)

f = 1/4 to 2 5/16 inches (5.9 to 59 mm)

15/8 to 16 9/16 inches (42 to 420 mm) when converted into a 35- mm still camera

F = 1.6 to 2.1

Filter diameter 2 1/8 inches (52 mm)

Color temperature

Auto/Indoors (3200K)/Outdoors (5800K)

Minimum illumination

4lux (F 1.6)

Illumination range

4lux to 100,000 lux

Recommended illumination

More than 100 lux

Shutter speed control

1/4 to 1/10000

Gain control

–3 to 18 dB

Aperture control

F 1.6 to F 11, CLOSE

Input and output connectors

S video output 4-pin mini DIN

Luminance signal: 1 Vp-p, 75ohm, unbalanced

Chrominance signal: 0.286 Vp-p, 75ohm, unbalanced

Video output

Phono jack, 1 Vp-p, 75ohm, unbalanced

BNC connector

Audio output

Phono jacks (2: stereo L and R) 327 mV, (at load impedance 47 kilohm) impedance less than 2.2kilohm

RFU DC OUT

Special minijack, DC 5V

Headphone jack

Stereo minijack (ø 3.5 mm)

LANC control jack

Stereo mini-minijack (ø 2.5 mm)

MIC jack

Stereo minijack, 0.388 mV low impedance with 2.5 to 3.0 V DC, output impedance 6.8 kilohm (ø

3.5mm)

Audio input

XLR jacks (2: CH-1 and CH-2)

Speaker

Dynamic speaker

DC input

4-pin connector

DV IN/OUT

4-pin special connector

Viewfinder connector

8-pin connector

General

Power requirements 7.2 V (battery pack)

8.4V (AC power adaptor)

Average power consumption

11.6W during camera recording

Operating temperature

32°F to 104°F (0°C to 40°C)

Storage temperature

–4°F to +140°F (–20°C to +60°C)

Dimensions (Approx.)

8 5/8 x 9 3/8 x 18 3/4 inches (216 x 237 x 474 mm) (w/h/d)

(When the viewfinder is lying flat)

Mass (Approx.)

7 lb 14 oz (3.6 kg) excluding the battery pack, lithium battery, cassette, lens cover and shoulder strap

10 lb 5 oz (4.7 kg) including the battery adaptor NPA-10000, battery pack NP-F930 (x3), lithium battery CR2025, cassette PDV-184ME, lens cover

Microphone

Stereo type

Supplied accessories

See page 5.

Design and specifications are subject to change without notice.
