SRP-270

2-2-3 Setting the DIP switch (IEEE1284 Parallel, USB Interface)

• DIP Switch 1

SW	FUNCTION	ON	OFF	DEFAULT
1	Emulation Selection	Refer to the following Table 1		OFF
2				OFF
3	Auto-Cutter	Enable	Disable	OFF
4	FONT SPACE	2	3	OFF
5	Function for Service Engineer			-
6				-
7				OFF
8	Korean Type Selection	Unified	Complete	OFF
• DIP Switch 2
SW	FUNCTION	ON	OFF	DEFAULT
1	Auto Line Feed	Always	Always	OFF
		Enabled	Disabled
2	Hex Dump	YES	NO	OFF
3	Reserved	-	-	OFF
4	Reserved	-	-	OFF
5	Reserved	-	-	OFF
6	Reserved	-	-	OFF
7	Reserved	-	-	OFF
8	Reserved	-	-	OFF

• Table 1 – Emulation Selection

SW – 1	SW – 2	MODE
OFF	OFF	Epson
OFF	ON	Citizen
ON	OFF	Star
• Table 2 – Baud rate (bps) Selection
Transmission speed	SW – 7	SW – 8
19200 baud	ON	ON
2400 baud	OFF	ON
4800 baud	ON	OFF
9600 baud	OFF	OFF

Rev. 3.02 - 12 -
