Canon 60D - page 158

158

z Menu Function Settings

Exposure simulationNExposure simulation displays and simulates how the brightness of the actual image (exposure) will look. The [Enable] and [Disable] settings are explained below:•Enable (g)The displayed image brightness will be close to the actual brightness (exposure) of the resulting image. If you set exposure compensation, the image brightness will change accordingly.•Disable (E)The image is displayed at the standard brightness to make the Live View image easy to see.

Quality Aspect Ratio and Pixel Count

3:2 4:3 16:9 1:1

3

1

5184x3456

(18.0 megapixels)

4608x3456

(16.0 megapixels)

5184x2912*

(15.1 megapixels)

3456x3456

(11.9 megapixels)

43456x2304

(8.0 megapixels)

3072x2304

(7.0 megapixels)

3456x1944

(6.7 megapixels)

2304x2304

(5.3 megapixels)

41 3888x2592

(10.1 megapixels)

3456x2592

(9.0 megapixels)

3888x2188*

(8.5 megapixels)

2592x2592

(6.7 megapixels)

a

61

2592x1728

(4.5 megapixels)

2304x1728

(4.0 megapixels)

2592x1456*

(3.8 megapixels)

1728x1728

(3.0 megapixels)

b1920x1280

(2.5 megapixels)

1696x1280*

(2.2 megapixels)

1920x1080

(2.1 megapixels)

1280x1280

(1.6 megapixels)

c720x480

(350,000 pixels)

640x480

(310,000 pixels)

720x400*

(290,000 pixels)

480x480

(230,000 pixels)

For asterisked image-recording quality, the pixel count does not exactly

match the set aspect ratio.

The area displayed for aspect ratios with an asterisk is slightly larger

than the recorded area. Check the captured images on the LCD monitor

when shooting.

If you print images shot with the EOS 60D with a 1:1 aspect ratio using

direct printing on a different camera, the image might not be correctly

printed.
