EL I M I N A T E I N T E R F E R E N C E Electrical appliances on the same circuit or operating near the computer can cause interference. Other causes of interference are:

Power extension cables

Keyboard and mouse extension cables

Too many devices on a power strip

Multiple power strips connected to the same electrical outlet

Printer Problems

CH E C K T H E P R I N T E R D O C U M E N T A T I O N See the printer documentation for setup and troubleshooting information.

EN S U R E T H A T T H E P R I N T E R I S T U R N E D O N See the printer documentation for power button information.

VE R I F Y T H E P R I N T E R C A B L E C O N N E C T I O N S

See the printer documentation for cable connection information.

Ensure that the printer cable is connected as described on page 21.

Ensure that the printer cables are securely connected to the printer and the computer.

TE S T T H E E L E C T R I C A L O U T L E T Ensure that the electrical outlet is working by testing it with another device, such as a lamp.

VE R I F Y T H A T T H E P R I N T E R I S R E C O G N I Z E D B Y WI N D O W S ®

1 Click the Start button.

2 Click Control Panel.

3 Click Printers and Other Hardware.

4 Click View installed printers or fax printers. If the printer is listed, right-click the printer icon.

5 Click Properties, and then select the Ports tab. For a parallel printer, ensure that the Print to the following port(s): setting is LPT1 (Printer Port). For a USB printer, ensure that the Print to the following port(s): setting is USB.

RE I N S T A L L T H E P R I N T E R D R I V E R See page 61.

CH E C K F O R I N T E R R U P T R E Q U E S T C O N F L I C T S See page 64.

HINT: Dell does not cover the printer’s warranty. If you need technical assistance for your printer, call the printer’s manufacturer. See the printer documentation for the correct phone number.

Solving Problems



51



Page 51
Image 51
Dell 2300C manual Printer Problems
