52 Installing System Components
Inside the System
CAUTION: Many repairs may only be done by a certified service technician.
Youshould only perform troubleshooting and simple repairs as authorized in
yourproduct documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the product.
CAUTION: This system must be operated with the system cover installed to
ensure proper cooling.
Figure 3-1. Inside the System
