88 Installing System Components

Figure 3-18. Removing and Installing the Mezzanine Card (10 GbE LAN)

1 mezzanine card (10 GbE LAN) 2 mezzanine-card cover

3 screws (3) 4 back panel

5 spacer pins (3)
