Installing System Components 57
Removing the Optional Internal Hard Drive 1
Turn off the system, including any attached peripherals, and disconnect
the system from its electrical outlet.
2
Open the system. See "Opening the System" on page 58.
3
Remove the cooling shroud. See "Removing the Cooling Shroud" on
page60.
4
Remove the eight screws that secure the internal hard drives to the hard-
drive assembly. See Figure3-5.
5
Remove the internal hard drives.
Figure 3-5. Removing and Installing the Internal Hard Drive
1 internal hard drives (2) 2 cooling shroud
3 hard-drive assembly 4 screws (8)
2
1
4
3
