78 Installing System Components
NOTE: Keep this bracket in case you need to remove the expansion card.
Filler brackets must be installed over empty expansion-card slots to maintain
FCC certification of the system. The brackets also keep dust and dirt out of the
system and aid in proper cooling and airflow inside the system.
9
Replace the cooling shroud. See "Installing the Cooling Shroud" on
page61.
10
Replace the system cover. See "Closing the System" on page59.
11
Reconnect the system and peripherals to their electrical outlets, and turn
on the system.
Figure 3-13. Removing and Installing the Expansion Card
1 expansion-card riser 2 expansion-card connector
3 expansion card 4 screw
4
2
1
3
