Installing System Components 87
4
Connect the RAID battery cable to the RAID battery connector on the
storage controller card. See Figure3-14.
5
Close the system. See "Closing the System" on page59.
6
Reconnect your system and peripherals to their electrical outlets, and turn
on the system.
Mezzanine Card (10 GbE LAN)Removing the Mezzanine Card (10 GbE LAN)
CAUTION: Many repairs may only be done by a certified service technician.
Youshould only perform troubleshooting and simple repairs as authorized in
yourproduct documentation, or as directed by the online or telephone service
andsupport team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came
withthe product.
1
Turn off the system, including any attached peripherals, and disconnect
the system from its electrical outlet.
2
Open the system. See "Opening the System" on page 58.
3
Remove the cooling shroud. See "Removing the Cooling Shroud" on
page60.
4
Remove the expansion-card riser assembly. See "Removing the Expansion-
Card Riser" on page74.
5
Remove the three spacer pins and the screw on the mezzanine card.
6
Remove the two screws securing the bracket and remove the card.
See Figure3-18.
7
If you are not installing another mezzanine card, install the
mezzanine-card cover and secure with two screws. See Figure3-18.
