Installing System Components 59
Figure 3-6. Opening and Closing the System
Closing the System
1
Place the cover on the chassis and offset it slightly toward the back of the
system, so that the hooks on the sides of the cover fit over the
corresponding slots on the sides of the chassis.
2
Slide the cover toward the front of the chassis till the screw hole on the
cover is aligned with the hole on the chassis.
3
Secure the cover with the securing screw. See Figure3-6.
4
Reconnect the system and peripherals to their electrical outlets and turn
on the system.
1 locking button 2 screw
3 system cover 4 traction pad
12
4
3
