HP h4100 Function Keys, Action, Keystroke Combination

Learning Input Methods

Function Keys

The integrated keyboard keys perform additional functions when pressed in the combinations indicated.

Keystroke Combination	Action

Shift + any letter key	Enters capital letter

Fn + Shift	Shift lock on/off

Fn + any key	Enters function characters on key
	(indicated in blue)

Fn + right Navigation Button	Highlights area to the right of the cursor

Fn + left Navigation Button	Highlights area to the left of the cursor

Fn + up Navigation Button	Highlights area from the cursor to one
	row above the cursor

Fn + down Navigation Button	Highlights area from the cursor to one
	row below the cursor

Fn +	Deletes characters without
	backspacing.

Fn + Enter (! )	Minimizes the current application

Fn + right arrow (B)	Moves cursor to the right

Fn + left arrow (C)	Moves cursor to the left

Fn + up arrow (G)	Moves cursor up one row

Fn + down arrow (V)	Moves cursor down one row

Note: The stylus can be used to select text or scroll through the displayed page.

User’s Guide

5–14
